Largebore Tractor Valve, Air-liquid Valve.
 |
| Type : Air-Liquid Valves | ||
| DJ No. | LENGTH | PARTS |
| TR618A | 51.5 | VC3, CH3,
#9200, HN1, RW11, RG7 |
| TR621A | (38.9+75.4)65 |
|
| TR622A | (44.5+115)90 |
|
| TR623A | (38.9+57.2)65 |
|
| TV-5905-65 | (25.4+70)65 |
|
| TV-5905-90 | (25.4+70)90 |
|
 |
| Type : Large Bore Valves For Off-The-Road-Equipment Clamp-In Tubeless Valves | |||
| DJ No. | STEM No. | LENGTH | PARTS |
| TR-J670-03 | TR-J670-02(straight) | 41.4 | VC7, C2, stem ,SP2 |
| TR-J650-03 | TR-J650-02(swivel bent ) | (27.4+79.2)80 |
VC7, C2, stem ,SP2 |
| TR-J651-03 | TR-J651-02(swivel bent ) | (32.3+119)90 |
VC7, C2, stem ,SP2 |
| TR-J652-03 | TR-J652-02(swivel bent ) | (27.4+140)86 |
VC7, C2, stem ,SP2 |
| TR-J653-03 | TR-J653-02(swivel bent ) | (27.4+63.5)80 |
VC7, C2, stem ,SP2 |
| TR-J654-03 | TR-J654-02(swivel bent ) | (27.4+79.2)60 |
VC7, C2, stem ,SP2 |
| TR-J655-03 | TR-J655-02(swivel bent ) | (27.4+79.2)74 |
VC7, C2, stem ,SP2 |
| TR-J656-03 | TR-J656-02(swivel bent ) | (66.5+93.7)90 |
VC7, C2, stem ,SP2 |
| TR-J657-03 | TR-J657-02(swivel bent ) | (27.4+101.6)80 |
VC7, C2, stem ,SP2 |
| TR-J658-03 | TR-J658-02(swivel bent ) | (27.4+139.7)80 |
VC7, C2, stem ,SP2 |
| TR-J659-03 | TR-J659-02(swivel bent ) | (48+88.9)90 |
VC7, C2, stem ,SP2 |
| TR-J660-03 | TR-J660-02(swivel bent ) | (48+222.3)90 |
VC7, C2, stem ,SP2 |
| TR-J669-03 | TR-J669-02(swivel bent ) | (27.4+63.5)90 |
VC7, C2, stem ,SP2 |
| Type : Turret Valves For Planetary Gear Wheels | |||||
| DJ No. | ANGLE BEND 1 | OFFSET LENGTH | ANGLE BEND 2 | HORIZONTAL LENGTH | REMARKS |
| TR-J690 | 28¢X | 14.2 | 28¢X | 119.1 | non-swivel |
| TR-J691 | 72¢X | - | - | 84.07 | non-swivel |
| TR-J692 | 18¢X | 14.2 | 28¢X | 119.1 | non-swivel |
| TR-J693 | 60¢X | 25.4 | 60¢X | 127 | non-swivel |
| TR-J694 | 62¢X | - | - | 88.9 | non-swivel |
| TR-J695 | 50¢X | 25.4 | 60¢X | 104.6 | non-swivel |
| TR-J696 | 42¢X | 23.1 | 42¢X | 108 | non-swivel |
Rim Hole : 20.5mm (0.807") core : TR-C2
  |
| Type : Super Large Bore Tubeless Valves | ||
| DJ No. | RIM HOLE | PARTS |
| TR-L870 | 20.5 (0.807") | SP8B, SP9, CH8, VC7, C2 |
| TR-910B | 20.5 (0.807") | SP8B, CH16, VC3 ,C2 |
| Type : Swivel Type Large Bore Valves For Trsp4000 Or TR-J650-197 (SP2) | |
| DJ No. | HORIZ. LENGTH |
| TR-J4000-2½ | 2.52"90¢X bend |
| TR-J4000-4½ | 4.53"90¢X bend |
| TR-J4000-5 | 5"90¢X bend |
| TR-J4000-6 | 6.02"90¢X bend |
| TR-J4000-7½ | 7.52"90¢X bend |
| TR-J4000-8 | 7.99"90¢X bend |
| TR-J4000-8¾ | 8.74"90¢X bend |
| TR-J4000-11½ | 11.50"90¢X bend |
| TR-J4000-12 | 12.01"90¢X bend |
| TR-J4000-24 | 24.02"90¢X bend |
| TR-J4000-28 | 27.9590¢X bend |
| TR-J4000-34 | 34.06"90¢X bend |
